RS485 adopts a half duplex working mode and supports multi-point data communication. The RS485 bus network topology generally adopts a terminal matched bus structure.
Product Features
1. Integrate multiple control modes
The L7RS series servo integrates single axis motion control suitable for IO signal/Modbus input, as well as speed/torque control for analog input and position control for pulse input.
Different control modes are suitable for different application scenarios.
2. Integrated internal single axis control function (PR)
The L7RS series driver integrates single axis control function, with target position, speed, and motion trajectory pre-set in the driver register, and real-time adjustment of motion parameters according to different application scenarios.
Simple point movement can be completed without the need for PLC pulse points (without PLC positioning function).
3. Supports RS485 networking communication control and IO point control
4. Rich PR functions
Instructions | four hundred and eighty-fiveBus type open-loop and closed-loop driver | |||
minimum | typical value | maximum | unit | |
output current | 0 | - | six thousand | mA |
Input power supply voltage | twenty | - | fifty | VAC |
twenty-four | thirty-six | seventy | VDC | |
Control signal input current | seven | ten | sixteen | mA |
insulation resistance | fifty | - | - | MΩ |
cooling method | natural coolingFan cooling | |
Usage environment | occasion | Cannot be placed next to other heat generating equipment. Avoid dust, oil mist, corrosive gases, high humidity, and strong vibration areas. Combustible gases and conductive dust are prohibited |
temperature | -25℃~fivefive℃ | |
humidity | forty~90%RH | |
vibration | 10~55Hz/0.15mm | |
storage temperature | -2five℃~65℃ | |
naming convention
